Small Indoor Outdoor Aluminum Lift Platform Portable Movable CE
Product Details:
| Place of Origin: | China |
| Brand Name: | YIMEISITE |
| Certification: | ISO 9001 ISO 14001 UDEM |
| Model Number: | YST-25 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | USD 1,000-3,000 per set |
| Packaging Details: | Export Non-Fumigation Wood Box |
| Delivery Time: | 20 Working Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Lift Capacity: | 227kg | Mobile Work Platform: | 3m Platform Height |
|---|---|---|---|
| Stowed Dimension: | 2200*1100*1890mm | Fork Lift Pockets: | Yes |
| Outrigger Footprint: | 1.45m X 1.45m | Voltage: | According To Local Voltage |
| Lift Drive: | Hydraulic,Electric Motor | Rated Loading Capacity: | 150kg |
| Product Type: | Electric Straddle Stacker | Overall Width: | 30 In |
| Model: | Vertical Mast Lift | Battery: | 2 X 12V/105Ah |
| Maximum Working Height: | 15 Ft | Load Capacity: | 1600 Kg / 2000 Kg |
| Service Weight: | 940 Kg / 960 Kg | ||
| Highlight: | Small aluminum lift platform,Indoor aluminum lift platform,Outdoor aluminum lift platform |
||
Product Description
Vertical Mast Lifts, aluminium alloy material, it has other names such as Aluminum Alloy Portable Lifter, Aluminum Alloy Telescoping Platform, Aluminum Alloy Retractable Platform, Aluminum Alloy Lightweight Lifting Device. Its lifting distance ranges from 2-12m.
| Lifting capacity | kg | 300 | 300 | 300 | 300 |
| Folding maximum height(guardrail unfolding) | mm | 2150 | 2275 | 2400 | 2525 |
| Folding maximum height(guardrail removed) | mm | 1190 | 1315 | 1440 | 1565 |
| Overall Length | mm | 2400 | 2400 | 2400 | 2400 |
| Overall Width | mm | 1150 | 1150 | 1150 | 1150 |
| Platform Size | mm | 2270×1150 | 2270×1150 | 2270×1150 | 2270×1150 |
| Minimumground clearance(folding) | mm | 110 | 110 | 110 | 110 |
| Minimumground clearance(rising) | mm | 20 | 20 | 20 | 20 |
| Wheelbase | mm | 1850 | 1850 | 1850 | 1850 |
| Minimum turn radius(inner wheel) | mm | 0 | 0 | 0 | 0 |
| Minimum turn radius(outer wheel) | mm | 2100 | 2100 | 2100 | 2100 |
| Power source | v/kw | 24/3.0 | 24/3.0 | 24/3.0 | 24/3.0 |
| Running speed(folding) | km/h | 4 | 4 | 4 | 4 |
| Running speed(rising) | km/h | 0.8 | 0.8 | 0.8 | 0.8 |
| Rising/falling speed | sec | 40/50 | 40/50 | 70/80 | 70/80 |
| Battery | V/Ah | 4×6/210 | 4×6/210 | 4×6/210 | 4×6/210 |
| Charger | V/A | 24/25 | 24/25 | 24/25 | 24/25 |
| Maximum climbing ability | % | 20 | 20 | 20 | 20 |
| Maximum working allowable angle | / | 2-3° | 2-3° | 2-3° | 2-3° |
| Way of control | / | Electro-hydraulic proportion control | |||
| Driver | / | Double front-wheel | |||
| Hydraulic drive | / | Double rear-wheel | |||
| Wheel size(stuffed&no mark) | / | Φ381×127 | Φ381×127 | Φ381×127 | Φ381×127 |
| Whole weight | kg | 1900 | 2080 | 2490 | 2760 |
Here is a domestic professional manufacturer of hydraulic lifting platforms, located in the "Hometown of China's Lifting Platform Manufacturing---Jiyang". We have a strong technical team, has developed a variety of hydraulic lifting platform products, has made a number of technical improvements, has a greater advantage in intelligence and reliability, and has applied for a number of technical patents, becoming a rising star in the industry. We independently developed and produced scissor lift series, aluminum alloy lift series, rail-type lifting platform, cylinder lift series and boarding bridges. Products are widely used in construction sites, factories, warehouses, stations, hotels, airports, docks, gas stations, stadiums, overhead pipelines and other high-altitude equipment installation, maintenance, cleaning and other scenarios, and also used in lifting equipment maintenance, field power equipment maintenance, etc.
