9m 11m Double Mast Aluminum Alloy Self Propelled Vertical Lift Platform
Product Details:
| Place of Origin: | China |
| Brand Name: | YIMEISITE |
| Certification: | ISO 9001 ISO 14001 UDEM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | USD 4,000-10,000 per set |
| Packaging Details: | Export Non-Fumigation Wood Box |
| Delivery Time: | 20 Working Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Lift Drive: | Hydraulic, Electric Motor | Color: | Blue,Customers' Requirements |
|---|---|---|---|
| Product: | Electric Aerial Order Picker | Moving Method: | Self-propelled |
| Overall Width: | 30 In | Platform Height: | 6m |
| Service Weight: | 940 Kg / 960 Kg | Machine Weight: | About 840kg |
| Loading Capacity: | 200kg | Gradeability: | 25% |
| Maximum Platform Height: | 8m | Model: | Vertical Mast Lift |
| Maximum Working Height: | 15 Ft | Turning Radius: | 1.4 M |
| Quality Management System: | ISO9001 | ||
| Highlight: | 9m Self Propelled Vertical Lift,11m Self Propelled Vertical Lift,Double Mast Self Propelled Vertical Lift |
||
Product Description
Specification
| MAST | model | platform height(m) | working height(m) | load capcity(kg) | woking platform size(mm) | suppy voltage(v) | power(kw) | weight(kg) | dimension(mm) |
| single mast | THWY4-100 | 4 | 5.7 | 100 | 600*600 | AC220/50HZ | 0.75 | 250 | 1280*800*1750 |
| THWY6-100 | 6 | 7.7 | 100 | 600*600 | AC220/50HZ | 0.75 | 280 | 1280*800*1900 | |
| THWY8-100 | 8 | 9.7 | 100 | 600*600 | AC220/50HZ | 0.75 | 300 | 1280*800*1980 | |
| THWY9-100 | 9 | 10.7 | 100 | 600*600 | AC220/50HZ | 1.1 | 320 | 1360*850*2000 | |
| THWY10-100 | 10 | 11.7 | 100 | 600*600 | AC220/50HZ | 1.1 | 340 | 1360*900*2100 | |
| double mast | THWY4-200 | 4 | 5.7 | 200 | 1100*600 | AC220/50HZ | 1.5 | 380 | 1300*900*1750 |
| THWY6-200S | 6 | 7.7 | 200 | 1100*600 | AC220/50HZ | 1.5 | 420 | 1300*900*1900 | |
| THWY8-200S | 8 | 9.7 | 200 | 1150*600 | AC220/50HZ | 1.5 | 550 | 1360*900*2000 | |
| THWY10-200S | 10 | 11.7 | 200 | 1350*600 | AC220/50HZ | 1.5 | 600 | 1560*970*1900 | |
| THWY12-200S | 12 | 13.7 | 200 | 1450*600 | AC220/50HZ | 1.5 | 700 | 1660*970*2000 | |
| THWY14-200S | 14 | 15.7 | 200 | 1450*600 | AC220/50HZ | 1.5 | 800 | 1660*1100*2350 | |
| three mast | THWY10-320 | 10 | 11.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 900 | 2100*1250*2000 |
| THWY12-320 | 12 | 13.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 900 | 2100*1250*2000 | |
| THWY14-320 | 14 | 15.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1000 | 2100*1250*2350 | |
| THWY16-320 | 16 | 17.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1000 | 2100*1250*2650 | |
| four mast | THWY10-420 | 10 | 11.7 | 200 | 1470*850 | AC220/50HZ | 2.2 | 1100 | 2000*1250*1900 |
| THWY12-420 | 12 | 13.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1200 | 2100*1250*2000 | |
| THWY14-420 | 14 | 15.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1300 | 2100*1250*2350 | |
| THWY16-420 | 16 | 17.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1500 | 2100*1250*2650 | |
| THWY18-420 | 18 | 19.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1700 | 2100*1350*2900 | |
| six mast | THWY18-620 | 18 | 19.7 | 150 | 1570*900 | AC220/50HZ | 2.2/1.1 | 1700 | 2500*1600*2450 |
| THWY20-620 | 20 | 21.7 | 150 | 1570*900 | AC220/50HZ | 2.2/1.1 | 1800 | 2500*1600*2450 | |
| THWY22-620 | 22 | 23.7 | 150 | 1570*900 | AC220/50HZ | 2.2/1.1 | 1900 | 2500*1600*2700 | |
| THWY24-620 | 24 | 25.7 | 150 | 1570*900 | AC220/50HZ | 2.2/1.1 | 2000 | 2500*1600*2850 | |
| lay down | THWYF14-200S14 | 14 | 15.7 | 200 | 1450*900 | AC220/50HZ | 1.5 | 1700 | 3000*1450*1990 |
| THWYF16-200S16 | 16 | 17.7 | 200 | 1450*900 | AC220/50HZ | 2.2 | 1900 | 3300*1450*2180 | |
| THWYF18-200S18 | 18 | 19.7 | 200 | 1500*900 | AC220/50HZ | 2.2 | 2400 | 3300*1450*2200 | |
| THWYF20-200S20 | 20 | 21.7 | 200 | 1500*900 | AC220/50HZ | 2.2 | 2600 | 3800*1450*2300 | |
| THWYF22-150S22 | 22 | 23.7 | 150 | 1500*900 | AC220/50HZ | 2.2 | 2800 | 4100*1450*2400 |
1. What 's our delivery time?
Normally we have inventory of the standard products, if not, we need 7-10 days to produce the standard products and 10-15 days for
the customized products.
2. What's our guarantee?
We have one year guarantee period for you, during this time, we can provide you with non-human damaged parts for free. And we 24h provide online service.
3.Do we accept customization?
Sure, we can customize a product according to your requirements. And we can do OEM&ODM for you.
4. Why should I buy from you not from other suppliers?
We are professional in producing the hydraulic lift equipment for logistics, warehouse, factory and construction using. We are a large-scale lifting platform manufacturing enterprise integrating R&D, production and sales.
5. What's our MOQ (minimum order quantity)?
It is one unit. But we have a good discount if you order more.
Normally we have inventory of the standard products, if not, we need 7-10 days to produce the standard products and 10-15 days for
the customized products.
2. What's our guarantee?
We have one year guarantee period for you, during this time, we can provide you with non-human damaged parts for free. And we 24h provide online service.
3.Do we accept customization?
Sure, we can customize a product according to your requirements. And we can do OEM&ODM for you.
4. Why should I buy from you not from other suppliers?
We are professional in producing the hydraulic lift equipment for logistics, warehouse, factory and construction using. We are a large-scale lifting platform manufacturing enterprise integrating R&D, production and sales.
5. What's our MOQ (minimum order quantity)?
It is one unit. But we have a good discount if you order more.
