Hotel Use Light Aluminium Single Mast Lift Garment Shops Building Material Shops
Product Details:
Place of Origin: | China |
Brand Name: | YIMEISITE |
Certification: | ISO 9001 ISO 14001 UDEM |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 Set |
---|---|
Price: | USD 4,000-10,000 per set |
Packaging Details: | Export Non-Fumigation Wood Box |
Delivery Time: | 20 Working Days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20 Sets Per Month |
Detail Information |
|||
Drive Speed: | 3.2 Km/h | Platform Height: | 6.57 M |
---|---|---|---|
Move Method: | Manual Push Type | Outrigger Footprint: | 1.34 M X 1.34 M |
Power Source: | DC Electric | Maximum Working Height: | 15 Ft |
Load Center: | 500 Mm | Working Height: | 8.57 M |
Color: | Blue,Customers' Requirements | Standard: | CE |
Type: | Vertical Mast Boom Lift | Battery: | 24V/210AH |
Weight: | 1,030 Kg | Overall Length: | 58 In |
Machine Weight: | About 420kg | ||
Highlight: | Hotel single mast lift,Light Aluminium single mast lift,Light Aluminium electric vertical mast lift |
Product Description
TECHNICAL PARAMETER
model | platform height(m) | working height(m) | load capcity(kg) | woking platform size(mm) | suppy voltage(v) | power(kw) | weight(kg) | dimension(mm) | |
single mast | THWY4-100 | 4 | 5.7 | 100 | 600*600 | AC220/50HZ | 0.75 | 250 | 1280*800*1750 |
THWY6-100 | 6 | 7.7 | 100 | 600*600 | AC220/50HZ | 0.75 | 280 | 1280*800*1900 | |
THWY8-100 | 8 | 9.7 | 100 | 600*600 | AC220/50HZ | 0.75 | 300 | 1280*800*1980 | |
THWY9-100 | 9 | 10.7 | 100 | 600*600 | AC220/50HZ | 1.1 | 320 | 1360*850*2000 | |
THWY10-100 | 10 | 11.7 | 100 | 600*600 | AC220/50HZ | 1.1 | 340 | 1360*900*2100 | |
double mast | THWY4-200 | 4 | 5.7 | 200 | 1100*600 | AC220/50HZ | 1.5 | 380 | 1300*900*1750 |
THWY6-200S | 6 | 7.7 | 200 | 1100*600 | AC220/50HZ | 1.5 | 420 | 1300*900*1900 | |
THWY8-200S | 8 | 9.7 | 200 | 1150*600 | AC220/50HZ | 1.5 | 550 | 1360*900*2000 | |
THWY10-200S | 10 | 11.7 | 200 | 1350*600 | AC220/50HZ | 1.5 | 600 | 1560*970*1900 | |
THWY12-200S | 12 | 13.7 | 200 | 1450*600 | AC220/50HZ | 1.5 | 700 | 1660*970*2000 | |
THWY14-200S | 14 | 15.7 | 200 | 1450*600 | AC220/50HZ | 1.5 | 800 | 1660*1100*2350 | |
three mast | THWY10-320 | 10 | 11.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 900 | 2100*1250*2000 |
THWY12-320 | 12 | 13.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 900 | 2100*1250*2000 | |
THWY14-320 | 14 | 15.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1000 | 2100*1250*2350 | |
THWY16-320 | 16 | 17.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1000 | 2100*1250*2650 | |
four mast | THWY10-420 | 10 | 11.7 | 200 | 1470*850 | AC220/50HZ | 2.2 | 1100 | 2000*1250*1900 |
THWY12-420 | 12 | 13.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1200 | 2100*1250*2000 | |
THWY14-420 | 14 | 15.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1300 | 2100*1250*2350 | |
THWY16-420 | 16 | 17.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1500 | 2100*1250*2650 | |
THWY18-420 | 18 | 19.7 | 200 | 1570*900 | AC220/50HZ | 2.2 | 1700 | 2100*1350*2900 | |
six mast | THWY18-620 | 18 | 19.7 | 150 | 1570*900 | AC220/50HZ | 2.2/1.1 | 1700 | 2500*1600*2450 |
THWY20-620 | 20 | 21.7 | 150 | 1570*900 | AC220/50HZ | 2.2/1.1 | 1800 | 2500*1600*2450 | |
THWY22-620 | 22 | 23.7 | 150 | 1570*900 | AC220/50HZ | 2.2/1.1 | 1900 | 2500*1600*2700 | |
THWY24-620 | 24 | 25.7 | 150 | 1570*900 | AC220/50HZ | 2.2/1.1 | 2000 | 2500*1600*2850 | |
lay down | THWYF14-200S14 | 14 | 15.7 | 200 | 1450*900 | AC220/50HZ | 1.5 | 1700 | 3000*1450*1990 |
THWYF16-200S16 | 16 | 17.7 | 200 | 1450*900 | AC220/50HZ | 2.2 | 1900 | 3300*1450*2180 | |
THWYF18-200S18 | 18 | 19.7 | 200 | 1500*900 | AC220/50HZ | 2.2 | 2400 | 3300*1450*2200 | |
THWYF20-200S20 | 20 | 21.7 | 200 | 1500*900 | AC220/50HZ | 2.2 | 2600 | 3800*1450*2300 | |
THWYF22-150S22 | 22 | 23.7 | 150 | 1500*900 | AC220/50HZ | 2.2 | 2800 | 4100*1450*2400 |
The lifting distance of our Vertical Mast Lifts spans from 2 to 12 meters, catering to a broad spectrum of height requirements. This flexibility makes them indispensable in diverse environments, ranging from hospitality settings like hotels and restaurants to retail spaces, garment shops, and building material stores. In machinery repair shops, manufacturing plants, and food & beverage factories, our lifts facilitate seamless access to hard-to-reach areas, enhancing productivity and safety.
Moreover, farms, residential properties, and retail outlets stand to benefit greatly from the convenience and ease of use that our Vertical Mast Lifts offer. Their compact design and user-friendly controls make them an excellent choice for tasks that demand precision and agility, whether you’re setting up displays in a retail store, maintaining equipment in a printing shop, or undertaking construction works.
In the energy and mining sectors, where safety is paramount and efficiency is key, our lifts provide a reliable solution for accessing elevated work areas. They are equally suited for food & beverage shops and advertising companies, aiding in tasks such as signage installation, maintenance, and inventory management at varying heights.
What sets our Vertical Mast Lifts apart is their ability to adapt to specific needs while maintaining a high standard of safety and performance. Equipped with robust safety features, these lifts ensure the well-being of operators and bystanders alike, making them a trusted addition to any workplace.
We understand that choosing the right equipment is crucial for the smooth operation of your business. Therefore, we offer customized solutions to tailor our Vertical Mast Lifts to your exact requirements. Our team of experts is always on hand to provide consultations, demos, and after-sales support, ensuring a seamless integration of our products into your operations.
As we strive to continuously innovate and improve, we invite you to explore the full potential of our Vertical Mast Lifts. We are confident that their versatility, robustness, and user-centric design will make them a valuable asset to your organization.
Should you have any questions, require further information, or wish to arrange a demonstration, please do not hesitate to reach out. We look forward to the opportunity of collaborating with you and contributing to the success of your endeavors.
